Custom Thermal CTP Double Layer Plates

Home / Products / Thermal CTP Plate(Double Layer)
Thermal CTP Plate(Double Layer)

Thermal CTP Plate(Double Layer)

Lecai Thermal-CTP plates are made for UV ink. It is compatible with ordinary ink. When using ordinary ink, the run-length of plates will be doubled. It is use for high-end commercial color printing and newspaper printing.

We are determined to create a "high quality, good service" brand image of "Le Cai" in the hearts of domestic and foreign customers.

Download template

Product Details

Application

Lecai Thermal UV-CTP plates are made for UV ink. It is compatible with ordinary ink. When using ordinary ink, the run-length of plates will be doubled. It is use for high-end commercial color printing and newspaper printing.

Characteristic

1. UV ink resistance

2. High-quality aluminum, composite grain and long run-length.

3. Capable of bright room operation.

4. High resolution and precise halftone dot reproduction.

5. Good development tolerance and convenient operation.

General Information
Plate Type Thermal CTP Plate(Double Layer)
Application High grade commercial and newspaper printing
Substrate Electro chemically Grained and Cathodic lithographic Aluminum
Aluminum alloy Standard 1050 Alloy
Coating Two-layer system,IR sensitive,positive acting
Gauge 0.15,0.20,0.25,0.30,0.40(mm)
Maximum short grain width 1380 mm
Length of Run Ordinary Ink:100,000 to 150,000 impressions
UV Ink:50,000 to 80,000 impressions



Exposing
Plate setters Kodak:Trendsetter/Lotem/Magnus
Fuji:Javelin T9000HS
Heidelberg:Top setter/Supra setter
Luscher:Xpose Plate setter
Screen:PT-R
Creo:Scitex
Exposure energy 90 -120 mJ/cm²
Spectral Sensitivity 800-850 nm -Peaks
Resolution 1-99%at 200 LPI
FM capability 20 micron stochastic
Image color Blue Green to Pale Green



Developing
Processor All the kind Brands.
Developer Kodak Gold Star or our Lecaideveloper
Processing temperature 23℃+/-2℃
Developing time 20-30 sec
Dynamic Supplement 80 -120 ml/m²
Storage and handling
Safelight Daylight handling
Shelf Life 12 months under recommended storage conditions
Storage and handling stored in a cool and dry environment,away from excessive cold, heat and humidity.

Get in Touch

Your name

Your e-mail*

Your message*

{$config.cms_name} submit
Jiangsu Lecai Printing Materials Co., Ltd.

About us

Jiangsu Lecai Printing Materials Co., Ltd. and Jiangsu Yuanrui Digital Technology Co., Ltd. are both manufacturing enterprises specializing in the production of printing plates, with an annual output of over 40 million square meters. We are China Wholesale OEM/ODM Thermal CTP Double Layer Plates Manufacturers and Custom Thermal CTP Double Layer Plates Suppliers, Factory, The rich experience accumulated in the printing production of the group over the past fifteen years and the unique process technology explored from practice have also ensured that our products have the advantages of high quality and high level, as well as fast photosensitivity, high resolution, large plate capacity, good ink balance, and high printing resistance. There are over 20 printing plate manufacturers worldwide, including Kodak, Agfa, Fuji from Japan, and Huaguang from China. Our Lecai ranking is approximately sixth in the world and third in China. In order to adapt to the increasingly severe environmental issues, LeCai successfully developed the process-less CTP plate in 2015, which filled the world's gap. While taking root in China, we also look at the world's larger and broader international market, mainly exporting to more than 50 countries, such as Germany, Spain, Italy, Brazil, Türkiye, Russia, and South Korea. We also actively seek partners at home and abroad.
View More

Thermal CTP Plate(Double Layer) Industry knowledge

Revolutionizing Printing: How Does the LeCai Dual-Layer Thermal CTP Plate Enhance Industry Standards?


In the field of printing technology, Thermal CTP Plate(Double Layer) plates are gradually becoming the first choice in the high-end commercial color printing and newspaper printing markets due to their high efficiency, accuracy, and environmental protection. As a leader in this field, Jiangsu Lecai Printing Materials Co., Ltd. and Jiangsu Yuanrui Digital Technology Co., Ltd. jointly launched Lecai thermal CTP plate (double-layer), which not only incorporates the latest scientific and technological achievements, but also Excellent performance and high-quality service have redefined the standards of printing plates and brought unprecedented changes to the industry.

One of the highlights of Lecai thermal CTP plate (double-layer) is its unique material formula, which makes the plate perfectly compatible with UV ink and ordinary ink. This technological breakthrough not only broadens the application range of plates, but also significantly improves the production flexibility and economic benefits of printing companies. While pursuing high-quality printing effects, users can flexibly select ink types according to actual needs without changing plates, enabling efficient printing in different scenarios. It is particularly worth noting that when using ordinary ink, the printing volume of the plate can be doubled, which is undoubtedly a huge advantage for large-scale, continuous printing operations, effectively reducing production costs and improving efficiency. market competitiveness.

As leaders in the industry, Jiangsu Lecai and Yuanrui Digital have more than fifteen years of experience in printing plate production. During this period, we continued to accumulate technology and optimize processes, forming unique technical barriers. Lecai thermal CTP plate (double-layer) is the crystallization of this profound heritage. It has multiple advantages such as fast photosensitivity, high resolution, large plate capacity, good ink balance, and strong printing durability. The combined effect of these characteristics enables printed matter to reach industry-leading levels in terms of color reproduction, detail expression, stability and durability. Whether it is delicate graphic printing or large-volume newspaper and magazine publishing, Lecai thermal CTP plate (double-layer) can easily meet the diverse needs of customers.

In the current global context of advocating green, low-carbon, and environmental protection, Lecai thermal CTP plate (double-layer) also demonstrates its sense of responsibility as an environmentally friendly printing material. By optimizing the material formula and production process, the plate has achieved remarkable results in reducing the emission of harmful substances and improving resource utilization. It not only complies with national and international environmental protection standards, but also helps printing companies reduce their impact on the environment in practical applications and achieve a win-win situation of economic and social benefits.

In addition to excellent product performance, Lecai also understands the importance of service to brand image. We always adhere to the principle of "customer first" and are committed to providing customers with a comprehensive and personalized service experience. From pre-sales consultation and technical support to after-sales tracking and problem solving, every step strives to be meticulous, professional and efficient. By establishing a complete service system, we strive to establish the brand image of "Lecai" with "high quality and good service" in the hearts of every customer, and have won widespread praise and trust from the market.

Lecai will continue to adhere to the corporate philosophy of "innovation, quality, and service", continue to increase investment in research and development, and promote the continuous progress of thermal CTP plate technology. We believe that through unremitting efforts and pursuit, Lecai thermal CTP plate (double-layer) will play a more important role in the printing industry and lead the industry to develop in a more efficient, environmentally friendly and smarter direction. At the same time, we also look forward to working hand in hand with more partners to jointly create a new chapter in printing technology.
