Thermal CTP Plate(Single Layer)

Thermal CTP Plate(Single Layer)

Lecai Thermal CTP plates are able to meet a wide variety of requirements for high-end commercial color printing and newspaper printing. It has the advantages of speedy plate -making, good tolerance level, precise halftone dot reproduction, good ink balance and long run-length.

We are determined to create a "high quality, good service" brand image of "Le Cai" in the hearts of domestic and foreign customers.

Download template

Product Details

Application

Lecai Thermal CTP plates are able to meet a wide variety of requirements for high-end commercial color printing and newspaper printing. It has the advantages of speedy plate -making, good tolerance level, precise halftone dot reproduction, good ink balance and long run-length.

Characteristic

1. High-quality aluminum, composite grain and long run-length.

2. Capable of bright room operation.

3. High resolution and precise halftone dot reproduction.

4. Good development tolerance and convenient operation.

General Information
Plate Type Thermal CTP Plate
Application High grade commercial and newspaper printing
Substrate Electro chemically Grained and Cathodic lithographic Aluminum
Aluminum alloy Standard 1050 Alloy
Coating IR sensitive,positive acting
Gauge 0.15,0.20,0.25,0.30,0.40 (mm)
Maximum short grain width 1380 mm
Length of Run Unbaked:80,000 to 100,000 impressions
Baked:Over 100000 impressions



Exposing
Plate setters Kodak:Trendsetter/Lotem/Magnus
Fuji:Javelin T9000HS
Heidelberg:Top setter/Supra setter
Luscher:Xpose Plate setter
Screen:PT-R
Creo:Scitex
Exposure energy 100 -120 mJ/cm²
Spectral Sensitivity 800-850 nm -Peaks
Resolution 1-99%at 300 LPI
FM capability 20 micron stochastic
Image color Blue



Developing
Processor All the kind Brands.
Developer Kodak Gold Star or our Lecaideveloper
Processing temperature 23℃+/-2℃
Developing time 20-30 sec
Dynamic Supplement 80 -120 ml/m²
Storage and handling
Safelight Daylight handling
Shelf Life 12 months under recommended storage conditions
Storage and handling stored in a cool and dry environment,away from excessive cold, heat and humidity.

Get in Touch

Your name

Your e-mail*

Your message*

{$config.cms_name} submit
Jiangsu Lecai Printing Materials Co., Ltd.

About us

Jiangsu Lecai Printing Materials Co., Ltd. and Jiangsu Yuanrui Digital Technology Co., Ltd. are both manufacturing enterprises specializing in the production of printing plates, with an annual output of over 40 million square meters. We are China Wholesale OEM/ODM Thermal CTP Single Layer Plates Manufacturers and Custom Thermal CTP Single Layer Plates Suppliers, Factory, The rich experience accumulated in the printing production of the group over the past fifteen years and the unique process technology explored from practice have also ensured that our products have the advantages of high quality and high level, as well as fast photosensitivity, high resolution, large plate capacity, good ink balance, and high printing resistance. There are over 20 printing plate manufacturers worldwide, including Kodak, Agfa, Fuji from Japan, and Huaguang from China. Our Lecai ranking is approximately sixth in the world and third in China. In order to adapt to the increasingly severe environmental issues, LeCai successfully developed the process-less CTP plate in 2015, which filled the world's gap. While taking root in China, we also look at the world's larger and broader international market, mainly exporting to more than 50 countries, such as Germany, Spain, Italy, Brazil, Türkiye, Russia, and South Korea. We also actively seek partners at home and abroad.
View More

Thermal CTP Plate(Single Layer) Industry knowledge

Unlocking the Power of Lecai's Single-Layer Thermal CTP Plates: The Question of Industry-Leading Innovation?


As a bridge between digital design and physical printing layout, thermal CTP Plate(Single Layer) plates are driving the transformation and development of the printing industry at an unprecedented speed. Jiangsu Lecai Printing Materials Co., Ltd. and Jiangsu Yuanrui Digital Technology Co., Ltd., as leaders in this field, rely on their outstanding R&D strength and production technology to specially launch single-layer thermal CTP plates, which not only meet the diversified needs of high-end commercial color printing and newspaper printing, but also set a benchmark of "high quality and good service" in the industry with its unique advantages.

Thermal CTP plates, as the name suggests, directly transfer image information from the computer to the printing plate through thermal technology, eliminating multiple steps such as film output, exposure, and development in the traditional platemaking process, greatly improving the efficiency and accuracy of platemaking. As a leader in this field, Lecai Thermal CTP Plate (Single Layer) not only simplifies the platemaking process with its single-layer design, but also shows extraordinary performance in terms of dot reproduction, water-ink balance, and continuous printing volume.

In the fast-paced modern printing market, time is money. Lecai thermal CTP plates stand out for their extremely fast plate-making speed, which greatly shortens the printing preparation time, allowing printing companies to respond quickly to market demand and seize every business opportunity. This advantage is particularly significant in the field of newspaper printing, ensuring the timeliness of news information and making information transmission faster and more accurate.

The diversity of the printing industry requires the plates to have a wide range of adaptability. With its excellent tolerance, Lecai thermal CTP plates can easily cope with the challenges of different materials and different printing conditions, whether it is highly saturated commercial colors or delicate graphic details, they can be perfectly presented. This wide adaptability makes Lecai plates the first choice for many printing companies.

The core of printing quality lies in the precise reproduction of dots. Lecai thermal CTP plates use advanced technology and processes to ensure the precise reproduction of dots, whether it is high-resolution images or delicate lines, they can be perfectly presented. This feature is particularly important in high-end commercial printing, giving printed products a more vivid and realistic visual effect and enhancing the market competitiveness of products.

Ink and water balance is a key link in the printing process, which directly affects the final effect of printed products. Lecai thermal CTP plates achieve excellent water-ink balance performance by optimizing the layout structure and material formula. Even in high-speed printing, they can maintain stable printing quality, reduce failure rate and improve production efficiency. This advantage makes Lecai plates perform well in printing tasks with long continuous printing volume, and become a powerful assistant for printing companies.

While pursuing quality, cost control is also an important part that printing companies cannot ignore. Lecai thermal CTP plates are known for their strong printability. They can extend the service life of plates and reduce the frequency of plate replacement while ensuring printing quality, thereby reducing printing costs. This is undoubtedly a great benefit for long-term, mass-produced printing projects.

Jiangsu Lecai Printing Materials Co., Ltd. and Jiangsu Yuanrui Digital Technology Co., Ltd., with their deep accumulation and continuous innovation in the field of printing plates, have launched single-layer thermal CTP plates, which not only represent the highest level of current printing technology, but also inject new vitality into the future development of the printing industry. Lecai thermal CTP plates are leading the printing industry towards a more efficient, accurate and environmentally friendly direction with their many advantages, such as fast plate-making speed, good tolerance, precise dot reproduction, good water-ink balance, long continuous printing volume and strong printing durability. In the future, Lecai will continue to uphold the brand concept of "high quality and good service", provide better solutions for global printing companies, and jointly write a new chapter in the printing industry.
