Thermal CTP Plate(Process-less)

Lecai Thermal-CTP plates are made for UV ink. It is compatible with ordinary ink. When using ordinary ink, the run-length of plates will be doubled. It is use for high-end commercial color printing and newspaper printing.
We are determined to create a "high quality, good service" brand image of "Le Cai" in the hearts of domestic and foreign customers.

Download template

Product Details

Application

Lecai thermal CTP plates can meet a wide variety of requirements for high-end commercial color printing and newspaper printing. It has the advantages of speedy plate-making, good tolerance level, precise halftone dot reproduction, good ink balance and long run-length. Process less CTP plates are new generation of environmentally friendly printing product, suitable for thermalCTP plate-making machine dedicated plate. It can be printed directly in the machine after exposure without any washing processing steps.



Characteristic

1. High-quality aluminum, composite grain, and long run length.

2. Capable of bright room operation.

3. High resolution and precise halftone dot reproduction.

4. Good development tolerance and convenient operation.

5. Environmental and pollution free.

6. Faster exposure.

General Information
Plate Type Process-less Thermal CTP Plate
Application High quality commercial and newspaper printing
Substrate Electro chemically Grained and Cathodic lithographic Aluminum
Aluminum alloy Standard 1050 Alloy
Coating IR sensitive,negative acting
Gauge 0.15,0.20,0.25,0.30,0.40(mm)
Maximum short grain width 1380 mm
Length of Run Ordinary Ink:80,000 to 100,000 impressions

Exposing
Plate setters Kodak:Trendsetter/Lotem/Magnus
Fuji:Javelin T9000HS
Heidelberg:Top setter/Supra setter
Luscher:Xpose Plate setter
Screen:PT-R
Creo:Scitex
Exposure energy 90-120 mJ/cm²
Spectral Sensitivity 800-850 nm -Peaks
Resolution 1-99% at 300 LPI
FM capability 20 micron stochastic
lmage color Light blue

Storage and handling
Safelight Handle under yellow safelight (UV free)
Shelf Life 6 months under recommended storage conditions
Storage and handling stored in a cool and dry environment,away from excessive cold, heat and humidity.

Get in Touch

Your name

Your e-mail*

Your message*

{$config.cms_name} submit
Jiangsu Lecai Printing Materials Co., Ltd.

About us

Jiangsu Lecai Printing Materials Co., Ltd. and Jiangsu Yuanrui Digital Technology Co., Ltd. are both manufacturing enterprises specializing in the production of printing plates, with an annual output of over 40 million square meters. We are China Wholesale OEM/ODM Process-less Thermal CTP Plates Manufacturers and Custom Process-less Thermal CTP Plates Suppliers, Factory, The rich experience accumulated in the printing production of the group over the past fifteen years and the unique process technology explored from practice have also ensured that our products have the advantages of high quality and high level, as well as fast photosensitivity, high resolution, large plate capacity, good ink balance, and high printing resistance. There are over 20 printing plate manufacturers worldwide, including Kodak, Agfa, Fuji from Japan, and Huaguang from China. Our Lecai ranking is approximately sixth in the world and third in China. In order to adapt to the increasingly severe environmental issues, LeCai successfully developed the process-less CTP plate in 2015, which filled the world's gap. While taking root in China, we also look at the world's larger and broader international market, mainly exporting to more than 50 countries, such as Germany, Spain, Italy, Brazil, Türkiye, Russia, and South Korea. We also actively seek partners at home and abroad.
View More

Thermal CTP Plate(Process-less) Industry knowledge

Revolutionizing Printing: The Question Behind Lecai's Thermal CTP Plate(Process-less)?


In the rapidly developing printing industry, technological innovation is constantly promoting the two-way improvement of production efficiency and quality. Among them, Thermal CTP Plate(Process-less), as an outstanding representative of the new generation of environmentally friendly printing technology, are gradually becoming the preferred material in the field of high-end commercial color printing and newspaper printing. Lecai, as a leader in this field, has not only reshaped the industry standards with its innovative thermal CTP plate products, but also established a brand image of "high quality and good service" worldwide.

With the increasing global awareness of environmental protection, the printing industry is also facing the pressure of transformation and upgrading. In the traditional platemaking process, the use of chemicals and the discharge of waste liquids have become increasingly prominent, and the emergence of Thermal CTP Plate(Process-less) provides solutions to these problems. Lecai thermal CTP plates, with its unique thermal imaging technology, have achieved zero chemical treatment and zero wastewater discharge in the platemaking process, truly achieving green environmental protection. This change not only responds to the call for global sustainable development, but also wins more customers for the company.

The core competitiveness of Lecai thermal CTP plates lies in its excellent technical performance. First of all, the substantial increase in plate-making speed is a highlight of thermal CTP technology. Compared with traditional plate-making methods, thermal CTP plates can complete plate-making in a very short time, greatly shortening the production cycle and improving work efficiency. At the same time, the high-tolerance design enables the plates to better adapt to various environmental conditions during the exposure process, ensuring the stability of plate-making quality.

In terms of printing quality, Lecai thermal CTP plates also perform well. Its accurate dot reproduction can perfectly present image details, making the printed products colorful and layered. In addition, the excellent ink color balance ability ensures the uniform distribution of ink during the printing process, effectively avoiding problems such as color difference and ink spots, and further improving the printing quality. What is even more commendable is that when using ordinary ink, the printing volume of Lecai thermal CTP plates can be doubled, which greatly reduces printing costs and improves economic benefits.

The wide application of Lecai thermal CTP plates is another manifestation of its market competitiveness. Whether it is high-end commercial color printing or large-scale newspaper printing, Lecai thermal CTP plates can handle it with ease. In the field of high-end commercial printing, its excellent printing quality and color expression can perfectly meet customers' needs for high-quality printed products; in the field of newspaper printing, its high-speed platemaking and long print volume greatly improve printing efficiency and reduce operating costs. In addition, Lecai thermal CTP plates are also suitable for various types of printing machines, providing printing companies with more flexible and diverse choices.

The reason why Lecai can stand out in the domestic and foreign markets is inseparable from its unremitting pursuit of quality and service. The company always adheres to the brand concept of "high quality and good service". From raw material procurement to production and manufacturing, and then to after-sales service, every link is strictly controlled to ensure the stability and reliability of product quality. At the same time, Lecai has also established a complete customer service system to provide customers with comprehensive technical support and solutions to help customers solve various problems encountered in practical applications. This customer-centric service concept has enabled Lecai to establish a good brand image in the hearts of customers and won wide recognition in the market.

As a major innovation in the printing industry, Lecai thermal CTP plates (free platemaking) have not only promoted the green and efficient development of printing technology, but also brought new development opportunities to printing companies. In the future development, Lecai will continue to uphold the enterprise spirit of "innovation, quality, and service", continuously develop more high-quality products, and contribute to the sustainable development of the printing industry. We believe that with the joint efforts of Lecai and other excellent companies, the future of the printing industry will be even better.
